WEBSERVER AIRZONE CLOUD DIN ETHERNET/WI-FI (AZX6WSCLOUDDIN [C/R])
Webserver for controlling Airzone systems through Airzone Cloud platform. Accessible through browser or App (available for
IOS and Android). Connected to router via Ethernet (AZX6WSCLOUDDINC) or WiFi (AZX6WSCLOUDDINR). Externally power
supplied at 110 / 230 Vac. Mounted on DIN rail or on wall.
Functionalities:
• Control of up to 32 systems.
• Configuration and control of zone parameters (Room and set-point temp., operating mode, etc.) and system
parameters via Airzone Cloud.
• Temperature and Operation mode time schedules.
• Multi-user and multi-session.
• External control through Airzone Cloud platform.
• Remote updates of the Webserver firmware and the systems connected to it.
• Remote error detection and error resolution.
AIRZONE SUPERMASTER CONTROLLER (AZX6CSMASTER [S/E] [B/G])
Monochrome LCD touch screen back-lighted controller for managing the system of the installation. Powered through AC unit
bus. Wall-mounted (AZX6CSMASTERS) or wall-embedded (AZX6CSMASTERE). Available in white and grey.
Functionalities:
• Up to 8 control groups.
• Operating mode and set-point temperature control.
• Forced mode control: it imposes the operating mode and the temperature, blocking the user control.
• Semi-forced mode control: it imposes the mode range and the temperature every hour.
• Forced mode control: it imposes the operating mode and the temperature, blocking the control for the user.
• Temperature time schedule for the installation.
• Operating mode time schedules.
AZX6CSMASTERE AZX6CSMASTERS
Important: This device is not compatible with the Production Control Board (AZX6CCP).
AZX6WEBSCLOUDDINC
AZX6WEBSCLOUDDINR
