AIRZONE CONTROLLER 3.0 GATEWAY (AZX6GTC XXX)
Gateway for the management of AC units compatible with Airzone control systems. Powered
by the indoor unit. Assembly and connection on the AC unit bus of the enabled Airzone
devices. Product developed and tested in collaboration with the manufacturer.
Features:
• Two-way communication of the basic control parameters depending on the demand of the
Airzone control system.
• Automatic control of speeds, enabling (generally) the operating without bypass.
• Adjustment of the set point temperature based on the selected temperatures in the
Airzone thermostats and the Eco-Adapt algorithm.
• Reading of the operating temperature of the system.
• Reading of warnings and errors of the controlled unit.
• Master control of the unit.
AIRZONE COMMUNICATION GATEWAY (AZX6QADAPT XXX)
Element that fully integrates AC units and Airzone zoning systems, enhancing the
performance of the installation:
• ON/OFF depending on the number of zones where there's demand.
• Automatic mode changeover (Stop, Ventilation, Cooling, Heating or Dry) from
master thermostat.
• Automatic fan speed selection based on the number of zones on demand.
• Set-point temperature adjustment based on the set-point temperatures of the zone thermostats of the system and
Eco Adapt algorithm.
AIRZONE 0-10 V FANCOIL CONTROL GATEWAY (AZX6010VOLTSZ)
Control gateway of air-to-water zoning units. Fan control through 0-10 V output and opening-
closing electrovalves Compatible with 2-pipe and 4-pipe installations. Externally powered at
110/230 Vac. Mounted on DIN rail or on wall.
Functionalities:
• Two relays for electrovalve control by demand.
• 0-10 V output for fan control.
• Automatic speed control based on the demand of the zones.
