Page 218
Chapter 11: MIDI Function
Model: MPC3000 (sequencer section) MIDI Implementation Chart Version: 3.0
Function Transmitted Recognized Remarks
Basic Default 1-16 1-16
Channel Channel 1-16 1-16
Default 3 1
Mode Messages ✕✕
Altered ✕✕
Note 0-127 0-127
Number True Voice 0-127 0-127
Velocity Note ON ❍❍
Note OFF ❍❍
After Key’s ❍❍
Touch Ch’s ❍❍
Pitch Bender ❍❍
Control 0-127 ❍❍See note below
Change
Prog ❍❍
Change True# 0-127 0-127
System Exclusive ❍❍
System :Song Pos ❍❍
:Song Sel ✕❍
Common :Tune ✕✕
System :Clock ❍❍
Real Time :Commands ❍❍
Aux :Local ON/OFF ✕✕
Mes- :All Notes Off ❍✕
sages :Active Sense ✕✕
:Reset ✕✕
Mode 1: OMNI ON, POLY Mode 2: OMNI ON, MONO ❍ : Yes
Mode 3: OMNI OFF, POLY Mode 4: OMNI OFF, MONO ✕ : No
Note: If the Convert Sustain Pedal To Duration field (accessed by pressing the MIDI key
and selecting option 2) is set to ON, then incoming controller 64 messages (sustain pedal)
will not be recorded into sequences. Instead, any notes that are currently pressed when a
Sustain On message is received are internally held on, even after they are released, until a
Sustain Off message is received. The result is that the individual durations of notes are
lengthened. This is explained further in the “MIDI Receive Channel, Local Mode, Soft Thru,
Note Variation Controller Assign and Sustain Pedal Processing” section of the manual,
earlier in this chapter.
