Chapter 2: The Basics
Page 16
sequence. To the right of this field is another field containing the
name for the selected sequence.
The Play/Record screen is one of many display screens available on
the MPC3000. Most of the panel keys present a unique screen, and
each screen has its own unique data fields. Try pressing a few of the
different keys in the Commands section of the panel, such as DISK
or TEMPO/SYNC.
The Numeric Keypad, Data Entry Control, and [+] & [–] Keys
Make sure that the Play/Record screen is showing. If not, press
MAIN SCREEN.
To change the data in a data field, move the cursor to the field and
type in the new number using the numeric keypad, followed by
ENTER. For example, to change to sequence number 2:
1. Move the cursor to the Seq field in the upper left corner;
2. Type 2, followed by the ENTER key.
Notice that the sequence name (located immediately to the right of
the sequence number) now changes automatically, because it must
now display the name of sequence 2.
Another use of the numeric keypad is to select from a list of menu
options presented on the screen. For example, pressing the PRO-
GRAM/SOUNDS key causes the following menu to be displayed:
===== Programs ===== ===== Sounds =====
1.Sel pgm, asn snds 5.Sample new sound
2.Envel,veloc,tune.. 6.Edit sound
3.Dynamic filter 7.Renam,cpy,delete
4.Copy, initialize 8.Audio trigger
==================== ==================
Select option:
When a screen like this is displayed, you are expected to select one
of the options by pressing a single number—it is not necessary to
press ENTER afterwards. Press MAIN SCREEN to return to the
Play/Record screen.
Another way of changing on-screen data is to use the data entry
control. While the cursor is in a data field, if the data entry control
is rotated one step to the right, the on-screen number will
increment. If the data entry control is rotated one step to the left,
