Akai S3000XL

EFFECTS
S3000XL Operator’s Manual Page 171
FX1 MOD/ECHO The output of FX1’s modulation/echo section will also be fed to the
reverb in RV3:
PATH CONTROL
MOD/ECHO
REVERB
PATH
PATH
DIST/EQ
L/R outs
L/R outs
RV3 REVERB
L/R outs
Again, you may have two reverbs applied to any sound routed to
the FX1 buss.
FX1 REVERB This routes the output of FX1’s reverb to RV3:
PATH CONTROL
MOD/ECHO
REVERB
PATH
PATH
DIST/EQ
L/R outs
L/R outs
RV3 REVERB
L/R outs
This routing allows you to ‘reverb reverb’! This has several uses.
You can set, for example, a gated reverb or reverse reverb effect
in FX1 and add to that ‘normal’ acoustic reverb. You could select
gated reverb in FX1 and add to that reverse reverb in RV3. There
are many possibilities and in conjunction with the PATH CONTROL
and the various sections’ level/pan controls, even more things are
possible and some very sophisticated multi-effects can be created.
NOTE: RV3 cannot take as its input FX2.
The same may be done with RV4 using FX2. The choices are identical to those described
above for RV3 except that RV4 takes as its input FX2. Please refer to the above
description for details.
NOTE: RV4 cannot take as its input FX1.
