EFFECTS EDIT
Page 186 S3000XL Operator’s Manual
DELAY AND ECHO EFFECTS
The next section in the effects allows you to set delay and echo effects. The delay line in
the multi-effects is dual channel allowing you to create ping pong and many other stereo
delay effects. It can also operate in a mono mode and this has the advantage of doubling
the available delay time. The echo/delay effects available are
MONO LEFT This will create a mono echo effect and the signal is derived through the
delay line’s left input.
DELAY L
DELAY R
HF DAMP
FBK
LEFT IN
MONO L+R This creates mono echo and delay effects but derives its input signal from
the left and right inputs to the delay line.
DELAY L
DELAY R
HF DAMP
FBK
LEFT IN
RIGHT IN
NOTE: Because the stereo mod section passes through the echo section, any stereo
mod effects you create (i.e. chorus, flange, phase, rotary speaker or autopan/frequency
mod effects) will be ‘monofied’ when MONO LEFT or MONO L+R effects are selected.
XOVER L&R This is a ‘pseudo-stereo’ delay effect that uses the two delay lines the
feedback path of which crosses over:
DELAY RIGHT
DELAY LEFT
LEFT IN
RIGHT IN
This gives rise to many interesting panning echo effects.
