EFFECTS EDIT
Page 200 S3000XL Operator’s Manual
Another way to picture the is as follows:
00
MOD/ECHO > REVREV > MOD/ECHO
-50 +50
At values of -01 to -50, more of the mod/echo section is fed to the reverb and setting of
+01 to +50, more of the reverb is fed into the mod/echo section.
As you can see, the offers a great deal of flexibility in the way the effects
chain is laid out with just one simple control. Normally, you will probably use a positive
setting (i.e. flange followed by reverb) and +25 is a good setting for most occasions but, to
change this direction (to flange the reverb, for example), simply set a negative value.
NOTE: Of course, the PATH CONTROL & OUTPUTS screen only applies to the multi-
effects channels FX1 and FX2.
When editing RV3 or RV4, the OUTPUT screen looks like this:
You only have access to the level and pan/balance of the reverb, of course.
