Connection to the Network
29
In order to configure the IP profile in your test unit follow these steps:
1. From the Home panel, go to CONFIG,
The port setup panel is displayed.
2. Select either Port A or Port B to enter in the port specific configuration.
3. Enter in Local profile.
Static IPv4 network
mask
Subnet mask used to identify the network address bits and
host address bits in the Static IPv4 address. The use of the
subnet mask is defined in RFC 1219. The subnet mask is
entered in decimal, four-dotted format and it must belong to
the same network (same network bits) than the current port.
The static addressing is used only if no dynamic address
configuration like DHCP is used for the port.
Static IPv4 gateway IP address corresponding to the network device used to send
IP packets to external networks. The gateway address is
configured in decimal, four-dotted format.
Static IPv4 DNS
server
IP address corresponding to the host used for domain name
resolution. A DNS server allows the user to identify
destinations by alphanumeric domain names rather than
numeric IP addresses. The DNS address has to be entered in
decimal, four-dotted format.
Leased IPv4 address Current DHCP-assigned IP address in a decimal four dotted
format. This is a read-only field that cannot be directly config-
ured by users
This setting makes sense only if Use DHCP is enabled.
Leased IPv4 network
mask
Current DHCP-assigned network mask in a decimal four dot-
ted format. This is a read-only field that cannot be directly
configured by users
This setting makes sense only if Use DHCP is enabled.
Leased IPv4 DNS
server
Current DHCP-assigned DNS server in a decimal four dotted
format. This is a read-only field that cannot be directly config-
ured by users.
This setting makes sense only if Use DHCP is enabled.
Leased IPv4 gateway Current DHCP-assigned default gateway in a decimal four
dotted format. This is a read-only field that cannot be directly
configured by users
This setting makes sense only if Use DHCP is enabled.
Table 2.6: Local Ethernet / IP Profile
