装回电池
警告: 拆装计算机内部组件之前，请阅读计算机附带的安全信息，并遵循拆装计算机内部组件之前中的步骤。拆装计算机
内部组件之后，请遵循 拆装计算机内部组件之后中的说明。有关其他最佳安全操作信息，请参阅 www.dell.com/
regulatory_compliance 上的 Regulatory Compliance（管制标准）主页。
Identifier GUID-FD9D275D-68B7-456F-9A35-3AFF103B5ED6
Status In Translation
Procedure
1 Align the screw holes on the battery with the screw holes on the palm-rest assembly.
2 Replace the six screws (M2.5x5) that secure the battery to the palm-rest assembly.
3 Route the battery cable through the routing guides on the computer base and connect the battery cable to the system
board.
22
