Alienware Area-51m - 卸下音频子板; Prerequisites; Procedure

Identifier GUID-3C23730D-19FE-4A80-8998-9A85C2DCE934
Status Translated
卸下音频子板
警告: 拆装计算机内部组件之前，请阅读计算机附带的安全信息，并遵循拆装计算机内部组件之前中的步骤。拆装计算机
内部组件之后，请遵循 拆装计算机内部组件之后中的说明。有关其他最佳安全操作信息，请参阅 www.dell.com/
regulatory_compliance 上的 Regulatory Compliance（管制标准）主页。
Identifier GUID-FAB3F27B-7168-4678-8B2A-62EEE97F0ACC
Status In Translation
Prerequisites
1 Remove the base cover.
2 Follow the procedure from step 1 to step 4 in Removing the hard drive.
Identifier GUID-426E11D6-17D0-4231-BAAA-22F99BB4010E
Status In Translation
Procedure
1 Disconnect the speaker cable from the audio daughter-board.
2 Peel the tape that secures the audio daughter-board cable to the audio daughter-board.
3 Open the latch and disconnect the audio daughter-board cable from the audio daughter-board.
4 Remove the three screws (M2.5x2.5) that secure the audio daughter-board to the palm-rest assembly.
