Alienware Area-51m - 装回触摸板; Procedure

Identifier GUID-B55423C5-03BB-46A2-9B5F-B8F3B4C854AB
Status Translated
装回触摸板
警告: 拆装计算机内部组件之前，请阅读计算机附带的安全信息，并遵循拆装计算机内部组件之前中的步骤。拆装计算机
内部组件之后，请遵循 拆装计算机内部组件之后中的说明。有关其他最佳安全操作信息，请参阅 www.dell.com/
regulatory_compliance 上的 Regulatory Compliance（管制标准）主页。
Identifier GUID-64C2C96B-FE72-4479-9D21-901503F9886C
Status In Translation
Procedure
1 Place the touchpad into the slot on the palm-rest assembly. Ensure to align the touchpad using the alignment pins on the
palm-rest assembly.
2 Slide and place the touchpad bracket into the slot on the palm-rest assembly.
3 Replace the ve screws (M2x2.5) that secure the touchpad bracket to the palm-rest assembly.
4 Slide the touchpad-button cable into the connector on the touchpad and close the latch to secure the touchpad-button
cable.
5 Adhere the touchpad cable to the touchpad bracket.
