Alienware Area-51m - Removing the Left Power-Adapter Port

Identifier GUID-C3C8548E-F690-4217-A385-81D10DA1C4B0
Status In Translation
Removing the left power-adapter port
警告: 拆装计算机内部组件之前，请阅读计算机附带的安全信息，并遵循拆装计算机内部组件之前中的步骤。拆装计算机
内部组件之后，请遵循 拆装计算机内部组件之后中的说明。有关其他最佳安全操作信息，请参阅 www.dell.com/
regulatory_compliance 上的 Regulatory Compliance（管制标准）主页。
Identifier GUID-7DAEB70A-6EC9-41F2-AF5F-1D84780ADE03
Status In Translation
Prerequisites
1 Remove the base cover.
2 Remove the battery.
3 Remove the wireless card.
4 Remove the solid-state drive (in SSD1 slot).
5 Remove the rear-I/O cover.
6 Remove the computer base.
7 Remove the heat-sink assembly.
Identifier GUID-344262DC-C253-439A-BBCD-64D5395B7303
Status In Translation
Procedure
1 Remove the screw (M2x3) that secures the power-adapter port bracket to the palm-rest assembly.
2 Slide the power-adapter port bracket o the palm-rest assembly.
3 Lift both power-adapter ports o the palm-rest assembly to uncross the cables.
75
