Alienware Area-51m - Replacing the System Board

Identifier GUID-67274E98-E2F1-4B7B-A903-F38BA6B62028
Status Translated
装回系统板
警告: 拆装计算机内部组件之前，请阅读计算机附带的安全信息，并遵循拆装计算机内部组件之前中的步骤。拆装计算机
内部组件之后，请遵循 拆装计算机内部组件之后中的说明。有关其他最佳安全操作信息，请参阅 www.dell.com/
regulatory_compliance 上的 Regulatory Compliance（管制标准）主页。
注: 计算机的服务标签存储在系统板中。装回系统板后，您必须在 BIOS 设置程序中输入服务标签。
注: 装回系统板会删除使用 BIOS 设置程序对 BIOS 所做的任何更改。您必须在装回系统板后再次进行相应的更改。
Identifier GUID-5A11D711-DDD9-4AE0-A828-100A7D94D454
Status In Translation
Procedure
1 Replace the left power-adapter port.
2 Turn the system board over and place it into the slot on the palm-rest assembly.
注: Do not keep the power-button board cable under the system board.
3 Replace the two screws (M2.5x5) that secure the system board to the palm-rest assembly.
4 Connect the keyboard cable to the system board and close the latch to secure the cable.
5 Connect the touchpad cable to the system board and close the latch to secure the cable.
6 Connect the audio daughter-board cable to the system board and close the latch to secure the cable.
7 Adhere the tape that secures the audio daughter-board cable to the system board.
8 Connect the connectors marked "MB" on the two graphics card cables to the system board.
