Alienware Area-51m - Removing the Graphics Card

Identifier GUID-B4F677A5-AC31-4D04-888C-5BEF42FDA20E
Status Translated
卸下图形卡
警告: 拆装计算机内部组件之前，请阅读计算机附带的安全信息，并遵循拆装计算机内部组件之前中的步骤。拆装计算机
内部组件之后，请遵循 拆装计算机内部组件之后中的说明。有关其他最佳安全操作信息，请参阅 www.dell.com/
regulatory_compliance 上的 Regulatory Compliance（管制标准）主页。
Identifier GUID-7DAEB70A-6EC9-41F2-AF5F-1D84780ADE03
Status In Translation
Prerequisites
1 Remove the base cover.
2 Remove the battery.
3 Remove the wireless card.
4 Remove the solid-state drive (in SSD1 slot).
5 Remove the rear-I/O cover.
6 Remove the computer base.
7 Remove the heat-sink assembly.
Identifier GUID-35F8E175-8B78-4A04-97FB-2CFEE70A3A06
Status In Translation
Procedure
1 Disconnect the graphics-card power cable from the system board.
2 Disconnect the graphics-card power cable from the graphics card.
3 Remove the two screws (M2x3) that secure the two graphics-card cable to the graphics card.
4 Remove the three screws (M2x3) that secure the graphics card to the system board.
