Alienware Area-51m - Replacing the Left Power-Adapter Port

Identifier GUID-5A2E2997-F8C9-4714-AF68-8D5977DBF24B
Status In Translation
Replacing the left power-adapter port
警告: 拆装计算机内部组件之前，请阅读计算机附带的安全信息，并遵循拆装计算机内部组件之前中的步骤。拆装计算机
内部组件之后，请遵循 拆装计算机内部组件之后中的说明。有关其他最佳安全操作信息，请参阅 www.dell.com/
regulatory_compliance 上的 Regulatory Compliance（管制标准）主页。
Identifier GUID-AA10A96D-A78B-4ACA-82F5-D0F5031A3389
Status In Translation
Procedure
1 Route the right power-adapter port cable under the left power-adapter port cable and place both power-adapter ports
into the slots on the palm-rest assembly.
2 Connect the right power-adapter port cable to the system board.
3 Slide and place the power-adapter board bracket on the palm-rest assembly.
4 Replace the screw (M2x3) that secures the power-adapter port bracket to the palm-rest assembly.
