Alienware Area-51m User Manual

Identifier GUID-A4C65F77-E1D1-4595-B52B-D281E90F786D
Status Translated
卸下散热器部件
警告: 拆装计算机内部组件之前，请阅读计算机附带的安全信息，并遵循拆装计算机内部组件之前中的步骤。拆装计算机
内部组件之后，请遵循 拆装计算机内部组件之后中的说明。有关其他最佳安全操作信息，请参阅 www.dell.com/
regulatory_compliance 上的 Regulatory Compliance（管制标准）主页。
警告: 在正常运行过程中，散热器可能会变得很热。接触散热器之前，请留有足够的时间让其冷却。
小心: 要最大限度地冷却处理器，请勿触摸散热器上的导热区域。皮肤上的油脂会降低导热油脂的导热性能。
Identifier GUID-0F717391-6837-4E42-AC2C-AB63B0492DBD
Status In Translation
Prerequisites
1 Remove the base cover.
2 Remove the battery.
3 Remove the wireless card.
4 Remove the solid-state drive (in SSD1 slot).
5 Remove the rear-I/O cover.
6 Remove the computer base.
Identifier GUID-292A396E-EC96-4F0D-B668-CE6EDA3C30F3
Status In Translation
Procedure
1 Disconnect the fan cables from the system board.
2 Remove the two screws (M2.5x5) that secure the heat-sink assembly to the palm-rest assembly.
3 In the reverse sequential order (8>7>6>5>4>3>2>1), loosen the eight captive screws that secure the heat-sink assembly
to the system board.
71

Alienware Area-51m Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Market positioning	Gaming
Pixel pitch	0.1989 x 0.1989 mm
LED backlight	Yes
Pixel density	127 ppi
Display surface	Matt
Display diagonal	17.3 \
Display brightness	300 cd/m²
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Memory slots	4x SO-DIMM
Internal memory	16 GB
Memory clock speed	2400 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	2 x 8 GB
HDD size	2.5 \
Storage media	Hybrid-HDD
Total storage capacity	1000 GB
Hybrid-HDD cache memory	8 GB
Speaker power	8 W
Front camera HD type	HD
Video capturing speed	30 fps
Front camera resolution	1280 x 720 pixels
Front camera signal format	720p
Front camera resolution (numeric)	0.92 MP
Antenna type	2x2
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Killer Wireless-AX 1650
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Keyboard backlit color	Various
Scalability	1S
Processor ARK ID	191792
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal solution specification	PCG 2015C
Battery weight	370 g
Battery voltage	11.4 V
Battery capacity	90 Wh
Battery recharge time	4 h
Number of battery cells	6
Operating shock	140 G
Operating altitude	0 - 3048 m
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating altitude	0 - 10668 m
Non-operating vibration	1.3 G
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19.5 V
Tjunction	100 °C
Processor cache	12 MB
Processor cores	8
Processor model	i7-9700
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor socket	LGA 1151 (Socket H4)
Processor codename	Coffee Lake
Processor frequency	3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4.7 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	65 W
Maximum number of PCI Express lanes	16
CUDA cores	1920
On-board graphics card ID	0x3E98
Discrete graphics card model	NVIDIA® GeForce RTX™ 2060
On-board graphics card model	Intel® UHD Graphics 630
Discrete graphics card memory	6 GB
Discrete graphics memory type	GDDR6
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1200 MHz

Weight and Dimensions

Depth	319.14 mm
Width	402.6 mm
Weight	3870 g
Height (rear)	31.2 mm
Height (front)	27.65 mm
