Alienware Area-51m - 装回 I;O 后护盖; Procedure; Post-Requisites

Identifier GUID-B723BCCE-51BE-4FF9-9DC7-9F88482EA486
Status Translated
装回 I/O 后护盖
警告: 拆装计算机内部组件之前，请阅读计算机附带的安全信息，并遵循拆装计算机内部组件之前中的步骤。拆装计算机
内部组件之后，请遵循 拆装计算机内部组件之后中的说明。有关其他最佳安全操作信息，请参阅 www.dell.com/
regulatory_compliance 上的 Regulatory Compliance（管制标准）主页。
Identifier GUID-3402CE1D-2F14-44A8-A086-0780C8CA5221
Status In Translation
Procedure
1 Align the tabs on the rear I/O cover with the slots on the computer base and snap the rear I/O cover into place.
2 Replace the two screws (M2.5x7) that secure the rear I/O cover to the palm-rest assembly.
3 Replace the four screws (M2.5x2.5) that secure the rear I/O cover to the computer base.
4 Adhere the tron-light cable to the computer base and connect the tron-light cable to the system board.
Identifier GUID-FB4A0598-CC04-47AC-97EA-1A2BDE31A1FD
Status In Translation
Post-requisites
Replace the base cover.
44
