Alienware Area-51m - Removing the Wireless Card

Identifier GUID-4AF7A7F4-79DC-43F4-A4DF-63362F890FB6
Status Translated
卸下无线网卡
警告: 拆装计算机内部组件之前，请阅读计算机附带的安全信息，并遵循拆装计算机内部组件之前中的步骤。拆装计算机
内部组件之后，请遵循 拆装计算机内部组件之后中的说明。有关其他最佳安全操作信息，请参阅 www.dell.com/
regulatory_compliance 上的 Regulatory Compliance（管制标准）主页。
Identifier GUID-A01821F4-5286-47E9-BE73-4FB22D51FE82
Status In Translation
Prerequisites
Remove the base cover.
Identifier GUID-14FF700F-F9C5-427D-987C-2655A91E317D
Status In Translation
Procedure
1 Locate the wireless card on your computer.
2 Remove the screw (M2x3) that secures the wireless-card bracket to the system board.
3 Slide and remove the wireless-card bracket from the wireless card.
4 Slide and remove the wireless card from the wireless-card slot.
27
