D-2 Default Data Maps
1734-IA2 Input Module
Message size: 1 Byte
1734-IB2 Sink Input Module
Message size: 1 Byte
1734-IB4 Sink Input Module
Message size: 1 Byte
7 6 5 4 3 2 1 0
Produces
(scanner Rx)
Ch1 Ch0
Consumes
(scanner Tx)
No consumed data
Where: Ch0 = channel 0, Ch1 = channel 1; 0 = off, 1 = on
7 6 5 4 3 2 1 0
Produces
(scanner Rx)
Ch1 Ch0
Consumes
(scanner Tx)
No consumed data
Where: Ch0 = channel 0, Ch1 = channel 1; 0 = OFF 1 = ON
7 6 5 4 3 2 1 0
Produces
(scanner Rx)
Ch3 Ch2 Ch1 Ch0
Consumes
(scanner Tx)
No consumed data
Where: Ch0 = input channel 0 Ch1 = input channel 1 Ch2 = input channel 2 Ch3 = channel 3
0 = OFF 1 = ON
