Allen-Bradley 1734-ADN - 1734-OB2 E Electronically Protected Output Module; 1734-OB2 EP Protected Output Module; 1734-OB4 E Electronically Protected Output Module

Publication 1734-UM002C-EN-P - July 2003
D-4 Default Data Maps
1734-OB2E Electronically Protected Output Module
Message size: 1 Byte
Message size: 1 Byte
1734-OB2EP Protected Output Module
Message size: 1 Byte
Message size: 1 Byte
1734-OB4E Electronically Protected Output Module
Message size: 1 Byte
7 6 5 4 3 2 1 0
Produces (scanner Rx) Not used Ch1 Ch0 Channel status
Where: 0 = no error 1 = error
7 6 5 4 3 2 1 0
Consumes (scanner Tx) Not used Ch1 Ch0 Channel state
Where: 0 = OFF 1 = ON
7 6 5 4 3 2 1 0
Produces (scanner Rx) Not used Ch1 Ch0 Channel status
Where: 0 = no error 1 = error
7 6 5 4 3 2 1 0
Consumes (scanner Tx) Not used Ch1 Ch0 Channel state
Where: 0 = OFF 1 = ON
7 6 5 4 3 2 1 0
Produces (scanner Rx) Not used Ch3 Ch2 Ch1 Ch0 Channel status
Where: 0 = no error 1 = error
