Default Data Maps D-3
1734-IV2 Source Input Module
Message size: 1 Byte
1734-IV4 Source Input Module
Message size: 1 Byte
1734-OA2 Output Module
Message size: 1 Byte
7 6 5 4 3 2 1 0
Produces
(scanner Rx)
Ch1 Ch0
Consumes
(scanner Tx)
No consumed data
Where: Ch0 = input channel 0 data Ch1 = input channel 1 data
7 6 5 4 3 2 1 0
Produces
(scanner Rx)
Ch3 Ch1 Ch1 Ch0
Consumes
(scanner Tx)
No consumed data
Where: Ch0 = input channel 0 Ch1 = input channel 1 Ch2 = input channel 2 Ch3 = input channel 3
7 6 5 4 3 2 1 0
Produces
(scanner Rx)
No produced data
Consumes (scanner Tx) Not used Ch1 Ch0 Channel state
Where: 0 = Off, 1 = On
