Allen-Bradley 1734-ADN User Manual

1 Publication 1734-UM002C-EN-P - July 2003
Chapter 3
Using Auto Start Mode
This chapter describes how to use the Auto Start Mode with your
POINT I/O DeviceNet adapter.
This chapter assumes you already have a DIN rail installed for your
POINT I/O system. There are five simple steps to the Auto Start Mode:
For more information on: See page:
Why Use Auto Start Mode? 3-2
Installing the Adapter 3-4
Wiring the Adapter 3-7
Installing the I/O Modules 3-8
Adding Non-Backplane Modules to Subnet (1734-ADNX Only) 3-9
Using RSNetWorx for DeviceNet 3-10
Beginning Auto Start Mode 3-11
Using Custom Configuration 3-13
Chapter Summary and What’s Next 3-14
1. Installing the Adapter 2. Wiring the Adapter
Adapter
Status
DeviceNet
Status
Subnet
Status
1734-ADNX
Field
Power
System
Power
3. Installing the I/O Modules
5. Using RSNetWorx
for DeviceNet
5. Beginning Auto Start Mode
24VDC
Source
Output
Module
Status
Network
Status
1734
OB4E
NODE:
0
1
2
3
4. 1734-ADNX Only
Add and Commission
Non-Backplane I/O
Modules to the Subnet
