Allen-Bradley 1734-ADN User Manual

1 Publication 1734-UM002C-EN-P - July 2003
Appendix A
Specifications
Specifications - 1734-ADN(X) DeviceNet Adapter Module
Communication Interface Specifications
Expansion I/O Capacity Up to 13 modules (13 times 75mA = 0.975, just under
the limit of 1.0A). The actual number of modules can
vary. Add up the current requirements of the
modules you want to use to make sure they do not
exceed the amperage limit of the 1734-ADN. (Note:
Total expansion up to 63 modules - 13 modules
maximum with 1734-ADN - add 1734-EP24DC
modules for an additional 17 modules (or less based
on current requirements), up to 63 module maximum)
Cat. No. PointBus Current Requirements
1734-232ASC 75mA
1734-485ASC 75mA
1734-IB2 75mA
1734-IB4 75mA
1734-IV2 75mA
1734-IV4 75mA
1734-OB2E 75mA
1734-OB2EP 75mA
1734-OB4E 75mA
1734-OV2E 75mA
1734-OV4E 75mA
1734-OW2 80mA
1734-OX2 100mA
1734-IE2C 75mA
1734-OE2C 75mA
1734-IE2V 75mA
1734-OE2V 75mA
1734-IA2 75mA
1734-IM2 75mA
1734-OA2 75mA
1734-IJ2 160mA
1734-IK2 160mA
1734-IR2 220mA
1734-SSI 110mA
1734-IT2I 175mA
1734-VHSC5 180mA
1734-VHSC24 180mA
DeviceNet Communication Rate 125K bit/s (500m maximum)
250K bit/s (250m maximum)
500K bit/s (100m maximum)
DeviceNet Cable Allen-Bradley part number 1485C-P1-Cxxx
Refer to publication DN-2.5 for more information
Module Location Starter module - left side of 1734 system
