Publication 1734-UM002C-EN-P - July 2003
Specifications A-3
Dimensions Inches
(Millimeters)
3.0H x 2.16W x 5.25L
(76.2H x 54.9W x 133.4L)
Environmental Conditions
Operational Temperature
Storage Temperature
Relative Humidity
ShockOperating
Non-operating
Vibration
-20 to 55
o
C (-4 to 131
o
F)
-40 to 85
o
C (-40 to 185
o
F)
5 to 95% noncondensing
30g peak acceleration, 11(±1)ms pulse width
50g peak acceleration, 11(±1)ms pulse width
Tested 5g @ 10-500Hz per IEC 68-2-6
Conductors Wire Size
Category
14 AWG (2.5mm
2
) - 22 AWG (0.25mm
2
) solid or
stranded maximum
3/64 inch (1.2mm) insulation maximum
2
1
Terminal Base Screw Torque 5-7 pound-inches (0.5-0.6Nm)
Field Wiring Terminations
DeviceNet
1 - Black Wire-V
2 - Blue WireCAN Low
3 - Bare WireShield
4 - White WireCAN High
5 - Red Wire+V
Power Supply 0 - No Connection1 - No Connection
2 - Chassis Ground3 - Chassis Ground
4 - Common5 - Common
6 - Supply7 - Supply
Mass 9.0 oz/255 grams
Agency Certification (when product
is marked)
CE marked for all applicable directives
C-Tick marked for all applicable acts
DeviceNet compatible as certified by ODVA, Inc.
1 Use this conductor category information for planning conductor routing as described in publication 1770-4.1, “Industrial
Automation Wiring and Grounding Guidelines.”
