Publication 2707-UM005AB-EN-P
Initial Setup and Mode Menu 3-5
Resetting the MicroView
Use the reset function to reset the MicroView after configuration changes using the
Mode Menu.
To reset the MicroView:
1. From the Mode Menu select [1] Reset.
You are prompted:
2. Press [1] on the keypad to initiate the reset.
The MicroView resets. This has the same effect as turning the
power off and on. The MicroView performs self diagnostic tests
and powerup displays as described in the Powerup Sequence.
Setting Communication
Parameters Manually
The communication function on the Mode Menu allows you to
manually set the baud rate of the communication port. Normally this
parameter is set automatically from the programming software when
an application is downloaded.
Select [2] Comm from the Mode Menu.
This menu displays:
Press [Prev] or [Next] to select a new rate: 300, 1200, 2400, 9600 or 19200.
Press [] to save the new Baud rate setting. The screen will display:
After the new parameter is saved, the MicroView will again display the Mode Menu
screen.
1 Reset
2 Comm
3 Spec
4 Other
1 = Reset
2 = Abort
1 Reset
2 Comm
3 Spec
4 Other
Baud Rate
“Next”
9600
Change
to
COPYING TO MEM
Please Wait . . .
1 Reset
2 Comm
3 Spec
4 Other
