1 Publication 2707-UM005B-EN-P
Chapter
6
Installing the MicroView Operator Interface
Objectives
This chapter contains the following sections:
Safety Guidelines
Install the MicroView terminal using publication NFPA 70E, Electrical
Safety Requirements for Employee Workplaces as a guide.
In addition, grounding is an important safety measure in electrical
installations. A source for grounding recommendations is the National
Electrical Code published by the National Fire Protection Association
of Boston Massachusetts.
Refer to the inside front cover of this manual for additional guidelines.
Operating Environment
The MicroView is rated for an operating temperature range of 32 to
131°F (0 to 55
°C). The storage temperature range is -4 to 158°F (-20 to
70°C).
The humidity rating is 5 to 95% relative humidity (non–condensing).
If you are using a DC power supply, check the environmental ratings
of the supply. The AC to DC Adapters (Catalog No. 2707-PS120 and
2707-PS220) are rated at 32-104
°F (0-40°C).
Enclosures
The Hand-Held MicroView (Catalog No. 2707-MVH232) does not need
to be mounted in an enclosure. A Faceplate Mounting Kit (Catalog No.
2707-MVMNT) is available if you wish to surface mount the
Hand-Held MicroView to a panel.
Section Page
Safety Guidelines 6-1
Operating Environment 6-1
Enclosures 6-1
Agency Certifications 6-2
Hazardous Locations 6-2
European Union Directive Compliance 6-2
Installation Instructions 6-3
Connecting DC Power 6-5
