Allen-Bradley 2707-MVP232 User Manual

Publication 2707-UM005B-EN-P
B-2 MicroView Cable Diagrams
Catalog No. 2707-NC9
Use the MicroView Communications cable (Catalog No. 2707-NC9) to
connect the MicroView to the MicroLogix controller for run-time
operation. The cable length is 15 meters.
Connects to MicroView
Communications Port
Connects to MicroLogix Controller
Communications Port
+24V dc
DC Com
Data In (RXD)
Data Out (TXD)
Signal Ground
+24V dc
DC Com
Data In (RXD)
Data Out (TXD)
Signal Ground
8-Pin Male C DIN Connector
8-Pin Male C DIN Connector
1
2
5
8
7
6
3
4
1
2
5
8
7
6
3
4
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
