Publication 2707-UM005B-EN-P
2-8 Microview Overview
Product Options
The table below lists the options available for the MicroView.
Product Accessories
The following accessories are available for the MicroView.
Item Catalog Number Description
MicroView 2707-MVH232 Hand-Held MicroView with RS-232
Communications Port
MicroView 2707-MVP232 Panel-Mount MicroView with RS-232
Communications Port
Programming
Services
2707-NP
(Version 5.00 or
later)
Use to create application screens for the
MicroView on a personal computer. Software
allows completed applications to be
transferred between the MicroView and a
personal computer. Will also support
application development for DTAM Plus and
DTAM Micro operator interfaces.
2707-NP2
(Version 1.00 or
later)
Use to create application screens for the
MicroView on a personal computer. Software
allows completed applications to be
transferred between a personal computer and
the MicroView.
Item Catalog Number Description
MicroView Face Plate
Mounting Kit
2707-MVMNT Allows the 2707-MVH232 hand-held
MicroView to be surface-mounted to a
panel. The MicroView unit slides into panel
adapter housing. An intregral cable
assembly connects the MicroView 8 pin DIN
connector to an 8 pin DIN connector on the
panel adapter.
MicroView
Programming Cable
2707-NC8 RS-232 cable connects MicroView and a
personal computer. Use to upload or
download applications with a personal
computer running DPS or MDPS software.
MicroLogix
Communications
Cable
1761-CBL-HM02-
2707-NC11
RS-232 cable connects MicroView to
MicroLogix controller for run-time
operations. (Length: 2 meters)
MicroLogix
Communications
Cable
2707-NC9 RS-232 cable connects MicroView to
MicroLogix controller for run-time
operations. (Length: 15 meters)
120V ac to dc Adapter 2707-PS120 Provides dc voltage output for the
MicroView. Operates on 120V ac input line
voltage.
220V ac to dc Adapter 2707-PS220 Provides dc voltage output for the
MicroView. Operates on 220V ac input line
voltage.
