1 Publication 2707-UM005B-EN-P
Chapter
5
Running Applications
Chapter Objectives
This chapter describes screen types and operating procedures that are
common to most applications. It contains the following sections:
Application Documentation
It is the responsibility of the application designer to document the
operation of an application program. This chapter only provides basic
guidelines. Before running an application, you should understand
what processes are being controlled and monitored.
Bit Write Mode
The application designer can assign the function keys [F1] and [F2] to
set or clear a bit at a controller address. This bit may control a variety
of processes. It is the responsibility of the application designer to
document the use of the bit write mode function keys.
Section Page
Application Documentation 5-1
Bit Write Mode 5-1
Screen Navigation 5-2
Screen Types 5-2
Menu and Sub-Menu Screens 5-4
Security Screens 5-4
Data Display Screens 5-5
Recipe Screens 5-6
ATTENTION
!
The function keys of the MicroView can be
assigned different functions depending upon the
application. The application designer must
document these functions. Make sure you
understand any function key operations prior to
operating the MicroView. Failure to do so may
result in unintended operation.
