Publication 2707-UM005AB-EN-P
3-6 Initial Setup and Mode Menu
Special Functions for
Controller Operations
The Special Menu item provides access to special features for the controller
operations.
Select [3] Spec from the Mode Menu.
This menu displays:
Below are brief descriptions of each menu item. Refer to Appendix C
for instructions on using the Special Menu items.
P-A/D
Use the Point Access / Display function to display and modify
controller data files. The P-A/D function does not allow you to write
to controller Input and Output files. Appendix C provides a listing of
the applicable file types for MicroLogix controllers along with
step-by-step instructions.
Mode
Select Mode to place the controller in either the run or program
modes. This may be useful if you need to halt the controller for
memory transfers.
Prgrm
Use the Program transfer function to initiate a transfer of data between
a MicroView and a MicroLogix controller. The Program Mode uploads
and downloads application programs between the MicroView and a
personal computer.
Clr Flt
Use the Clear Fault function to clear all major and minor faults in the
controller.
1 Reset
2 Comm
3 Spec
4 Other
1 P-A/D
2 Mode
3 Prgrm
4 Clr Flt
