Publication 2707-UM005B-EN-P
Troubleshooting and Maintenance 8-13
The MicroView displays either a Pass or Fail message.
6. Pressing any key terminates the Comm. Port test.
The next test selection screen is displayed.
7. To terminate all test functions, press the [NEXT] and [PREV] keys
to display Reset in the test selection area. Press [ ] to reset the
terminal.
Watchdog Test
Tests the hardware watchdog operation.
To perform the Watchdog Test:
1. Use the [NEXT] and [PREV] keys to display Watchdog on the test
selection screen.
2. Press [ ] to initiate the test.
The MicroView displays either a Pass or Fail message.
3. Pressing any key terminates the Watchdog test.
The next test selection screen is displayed.
4. Press [ ] to reset the terminal and exit the test sequence.
Comm Port: PASS
Any Key to Cont.
Diagnostic Tests
Watchdog
Diagnostic Tests
Watchdog
Watchdog: PASS
Any Key to Cont.
Diagnostic Tests
Reset
