3-4 Initial Setup and Mode Menu
Mode Menu
Access the Mode Menu by pressing the [MODE] key. All other
functions are halted when the menu is displayed. The Mode Menu
provides access to four functions:
Select a menu item by pressing the corresponding numeric key [1] to
[4]. The menu structure is shown below:
1 Reset
2 Comm
3 Spec
4 Other
Resets the MicroView
Special
Controller Operations
Configures MicroView
Communications Port
Sets Master
Security Code
Enables / Disables
Scaling
Performs
Functional Tests
Simulates Controller
Communications
Exits to
Mode Menu
1 Reset
2 Comm
3 Spec
4 Other
1 P-A/D
2 Mode
3 Prgrm
4 Clr Flt
Baud Rate
“Next”
9600
Change
to
1 Code
2 Scale
3 Sim
4 Test
5 Ex
To Next Page
