MicroView Special Controller Functions C-5
Reading / Writing
Controller Binary and
Integer Files
To read/write the contents of controller Binary and Integer
files:
You can read or write the element, decimal data and binary data fields
of Bit and Integer files. The hexadecimal data field is read-only.
1. Press [1] P-A/D from the Special Menu to access the P-A/D
function.
You are prompted for a file type:
2. Press [NEXT] and [PREV] keys to scroll through the file types.
Select either Binary (B) or Integer (N) and press [ ].
You are prompted for an element number:
3. Enter the element number and press [ ].
You are shown the decimal value of the data:
Initially, you are shown a decimal value for the status. If you
press [NEXT], the hexadecimal format is displayed:
Pressing [NEXT] again displays the binary value:
4. To change a value, move the cursor into the data field using the
[NEXT] or [PREV] keys. Enter the new data. If you are editing
binary data, use the [+/-] key to toggle the data between 1 and 0.
5. Press [ ] to load the new data into the file element.
6. To exit, press the [CE] key to return to the initial P-A/D screen.
You can press the [CE] key at any time during the P-A/D
function.
7. Press the [MENU] key at any time to exit the P-A/D function and
display the Main Menu.
Select File Type:
O (Output)
Elem=___________
Data Format
Data
File=N7
Elem=10
DEC
19774
File=N7
Elem=10
HEX
4D3E
File=N7
0011111001001101
Elem=10
