Rockwell Automation Publication KNX-RM003B-EN-P - March 2019 39
Kinetix 6000 and Kinetix 6200/6500 Drive Systems
Bulletin MPF Motor Performance Specifications with Kinetix 6000 (200V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, see Motion Analyzer software.
Rotary Motor
Cat. No.
Rated Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 6000
200V-class Drives
MPF-A310P 4750 5000 4.50 1.58 (14.0)
10.5 2.91 (25.7)
0.73
2094-AMP5-S
14.0 3.61 (31.9) 2094-AM01-S
MPF-A320H 3350 3500 6.10 3.05 (27.0)
17.0 6.97 (61.6)
1.0
2094-AM01-S
19.3 7.91 (70.0) 2094-AM02-S
MPF-A320P 4750 5000
8.50 2.88 (25.5) 17.0 5.07 (44.8)
1.3
2094-AM01-S
9.00 3.05 (27.0) 29.5 7.91 (70.0) 2094-AM02-S
MPF-A330P 5000 5000 12.0 3.85 (34.0)
30.0 8.47 (74.9)
1.6
2094-AM02-S
38.0 10.32 (91.2) 2094-AM03-S
MPF-A430H 3500 3500 12.2 6.21 (55.0)
30.0 13.20 (117)
1.8
2094-AM02-S
45.0 19.82 (175) 2094-AM03-S
MPF-A430P 5000 5000 16.80 5.94 (52.5)
49.0 15.36 (136)
1.9
2094-AM03-S
67.0 19.80 (175) 2094-AM05-S
MPF-A4530K 4000 4000 19.50 8.08 (71.4)
49.0 17.01 (150)
2.3
2094-AM03-S
62.0 20.30 (179) 2094-AM05-S
MPF-A4540F 3000 3000 18.40 10.15 (89.7)
49.0 23.56 (208)
2.5
2094-AM03-S
58.0 27.10 (239) 2094-AM05-S
MPF-A540K 4000 4000
24.5 11.40 (100) 49.0 21.68 (192)
4.1
2094-AM03-S
41.5 19.42 (171) 73.4 31.55 (279) 2094-AM05-S
