Rockwell Automation Publication KNX-RM003B-EN-P - March 2019 17
Kinetix 6000 and Kinetix 6200/6500 Drive Systems
Kinetix 6000 and Kinetix 6200/6500 (400V-class) Drives
with MP-Series Low Inertia Motors
This section provides system combination information for the Kinetix 6000 and the Kinetix 6200/6500 (400V-class)
drives when matched with MP-Series low-inertia motors. Included are motor power/brake and feedback cable catalog
numbers, system performance specifications, and the optimum torque/speed curves.
Bulletin MPL Motor Cable Combinations
For cable configuration illustrations and feature descriptions, by catalog number, see 2090-Series Motor/Actuator Cables Overview beginning on page 8.
Motor-end connector kits, and panel-mounted breakout components (drive end), are available for motor power/brake and feedback cables. See Optional Drive Accessories on page 6
.
Cable length xx is in meters. See the Kinetix Motion Accessories Technical Data, publication KNX-TD004
, for standard cable lengths.
IMPORTANT When using Kinetix 6000 (series B or C) drives, configured for enhanced peak performance, you can usually achieve full motor
performance with a smaller drive. Kinetix 6200 and Kinetix 6500 drives are configured for enhanced peak performance by
default. Expect the same peak performance from Kinetix 6200/6500 drives as you get from Kinetix 6000 (series B or C) drives
configured for enhanced peak performance.
See Kinetix Servo Drives Specifications Technical Data, publication KNX-TD003
, for more information.
IMPORTANT The MP-Series low-inertia motors on this page are equipped with DIN connectors (specified by 7 in the catalog number) and are
not compatible with cables designed for motors equipped with bayonet connectors (specified by 2 in the catalog number). The
motors with bayonet connectors (for example, MPL-A310P-xx2xAA) are being discontinued and require 2090-XXNxMP
(bayonet) cables. For help with migration or to select bayonet cables, contact your Rockwell Automation sales representative.
Motor Cat. No. (400V-class) Motor Power/Brake Cable Motor Feedback Cable
(1)
(1) Use low-profile connector kit (catalog number 2090-K6CK-D15M) with flying-lead cables on the drive end. See Required Drive Accessories on page 4.
MPL-B1510V-xx7xAA, MPL-B1520U-xx7xAA, MPL-B1530U-xx7xAA
2090-CPxM7DF-16AAxx (standard, non-flex)
2090-CPxM7DF-16AFxx (continuous-flex)
2090-CFBM7DF-CEAAxx or
(2)
(3)
2090-CFBM7DD-CEAAxx (standard, non-flex)
2090-CFBM7DF-CEAFxx or
2090-CFBM7DD-CEAFxx (continuous-flex)
Absolute High-resolution Feedback
2090-XXNFMF-Sxx (standard)
(4)
2090-CFBM7DF-CDAFxx (continuous-flex)
Incremental Feedback
2090-CFBM7DF-CEAAxx (standard, non-flex)
(5)
2090-CFBM7DF-CEAFxx (continuous-flex)
Resolver Feedback
(2) Applies to Kinetix 6000 drives and MPL-B3xxx-M/S…MPL-B9xxx-M/S motors with absolute high-resolution feedback.
(3) Applies to Kinetix 6000 drives and MPL-B15xxx-V/E…MPL-B2xxx-V/E motors with absolute high-resolution feedback.
(4) Applies to Kinetix 6000 drives and MPL-B15xxx-H…MPL-B45xxx-H motors with incremental feedback.
(5) Applies to Kinetix 6000 drives and MPL-B3xxx-R…MPL-B45xxx-R motors with resolver feedback.
MPL-B210V-xx7xAA, MPL-B220T-xx7xAA, MPL-B230P-xx7xAA
MPL-B310P-xx7xAA, MPL-B320P-xx7xAA, MPL-B330P-xx7xAA
MPL-B420P-xx7xAA, MPL-B430P-xx7xAA
MPL-B4530F-xx7xAA, MPL-B4530K-xx7xAA,
MPL-B4540F-xx7xAA, MPL-B4560F-xx7xAA
MPL-B520K-xx7xAA
MPL-B540D-xx7xAA, MPL-B540K-xx7xAA, MPL-B560F-xx7xAA
2090-CPxM7DF-14AAxx (standard, non-flex)
2090-CPxM7DF-14AFxx (continuous-flex)
MPL-B580F-xx7xAA, MPL-B580J-xx7xAA,
MPL-B640F-xx7xAA
2090-CPxM7DF-10AAxx (standard, non-flex)
2090-CP
xM7DF-10AFxx (continuous-flex)
MPL-B660F-xx7xAA, MPL-B680D-xx7xAA,
MPL-B960B-xx7xAA, MPL-B980B-xx7xAA
2090-CPxM7DF-08AAxx (standard, non-flex)
2090-CPxM7DF-08AFxx (continuous-flex)
MPL-B680F-xx7xAA, MPL-B680H-xx7xAA,
MPL-B860D-xx7xAA, MPL-B880C-xx7xAA
MPL-B880D-xx7xAA
2090-CPxM7DF-06AAxx (standard, non-flex)
