Rockwell Automation Publication KNX-RM003B-EN-P - March 2019 29
Kinetix 6000 and Kinetix 6200/6500 Drive Systems
Kinetix 6000 and Kinetix 6200/6500 (400V-class) Drives
with MP-Series Medium Inertia Motors
This section provides system combination information for the Kinetix 6000 and Kinetix 6200/6500 (400V-class) drives
when matched with MP-Series medium-inertia motors. Included are motor power/brake and feedback cable catalog
numbers, system performance specifications, and the optimum torque/speed curves.
Bulletin MPM Motor Cable Combinations
For cable configuration illustrations and feature descriptions, by catalog number, see 2090-Series Motor/Actuator Cables Overview beginning on page 8.
Motor-end connector kits, and panel-mounted breakout components (drive end), are available for motor power/brake and feedback cables. See Optional Drive Accessories on page 6
.
Cable length xx is in meters. See the Kinetix Motion Accessories Technical Data, publication KNX-TD004
, for standard cable lengths.
IMPORTANT When using Kinetix 6000 (series B or C) drives, configured for enhanced peak performance, you can usually achieve full motor
performance with a smaller drive. Kinetix 6200 and Kinetix 6500 drives are configured for enhanced peak performance by
default. Expect the same peak performance from Kinetix 6200/6500 drives as you get from Kinetix 6000 (series B or C) drives
configured for enhanced peak performance.
See Kinetix Servo Drives Specifications Technical Data, publication KNX-TD003
, for more information.
Motor Cat. No. (400V-class) Motor Power/Brake Cable Motor Feedback Cable
(1)
(1) Use low-profile connector kit (catalog number 2090-K6CK-D15M) with flying-lead cables on the drive end. See Required Drive Accessories on page 4.
MPM-B1151x, MPM-B1152x, MPM-B1153E, MPM-B1153F
2090-CPxM7DF-16AAxx (standard, non-flex)
2090-CPxM7DF-16AFxx (continuous-flex)
2090-CFBM7DF-CEAAxx or
2090-CFBM7DD-CEAAxx (standard, non-flex)
2090-CFBM7DF-CEAFxx or
2090-CFBM7DD-CEAFxx (continuous-flex)
Absolute High-resolution Feedback
2090-CFBM7DF-CEAAxx (standard, non-flex)
(2)
2090-CFBM7DF-CEAFxx (continuous-flex)
Resolver Feedback
(2) These cables apply to Kinetix 6000 drives and MPM-Bxxxxx-2 motors (resolver feedback).
MPM-B1302F, MPM-B1302M, MPM-B1304C, MPM-B1304E
MPM-B1651C, MPM-B1652C
MPM-B1153T
2090-CPxM7DF-14AAxx (standard, non-flex)
2090-CPxM7DF-14AFxx (continuous-flex)
MPM-B1302T, MPM-B1304M
MPM-B1651F, MPM-B1653C
MPM-B1651M, MPM-B1652E, MPM-B1652F, MPM-B1653E
2090-CPxM7DF-10AAxx (standard, non-flex)
2090-CPxM7DF-10AFxx (continuous-flex)
MPM-B2152C, MPM-B2153B
MPM-B1653F
2090-CPxM7DF-08AAxx (standard, non-flex)
2090-CPxM7DF-08AFxx (continuous-flex)
MPM-B2152F, MPM-B2152M, MPM-B2153E, MPM-B2153F,
MPM-B2154B, MPM-B2154E, MPM-B2154F
Bulletin MPM Motor Performance Specifications with Kinetix 6200/6500 (400V-class) Drives
Rotary Motor
Cat. No.
Base Speed
rpm
Rated Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 6200/
Kinetix 6500
400V-class Drives
MPM-B1151F 3000 4000 5000 2.71 2.3 (20.3) 9.9 6.6 (58.4) 0.75 2094-BMP5-M
MPM-B1151T 6000 5000 7000 5.62 2.3 (20.3) 20.5 5.8 (51.3) 0.90 2094-BM01-M
MPM-B1152C 1500 2500 3000 3.61 5.0 (44.2) 12.4 13.5 (119) 1.20 2094-BM02-M
MPM-B1152F 3000 4000 5200 6.17 5.0 (44.2) 21.1 13.3 (118) 1.40 2094-BM01-M
MPM-B1152T 6000 4000 7000 11.02 5.0 (44.2) 36.5 13.1 (116) 1.40 2094-BM02-M
MPM-B1153E 2250 3000 3500 6.21 6.5 (57.5) 21.6 19.7 (174) 1.40 2094-BM01-M
MPM-B1153F 3000 4000 5500 9.20 6.4 (56.6) 32.0 19.7 (174) 1.40 2094-BM02-M
MPM-B1153T 6000 4000 7000 15.95 6.4 (56.6) 45.0 14.5 (128) 1.45 2094-BM03-M
MPM-B1302F 3000 4000 4500 8.57 6.6 (58.4) 21.5 13.0 (115) 1.65 2094-BM01-M
