Allen-Bradley Kinetix 6000 - Kinetix 6000 and Kinetix 6200;6500 (400 V-class) Drives;MP-Series Low Inertia Motor Curves

Rockwell Automation Publication KNX-RM003B-EN-P - March 2019 21
Kinetix 6000 and Kinetix 6200/6500 Drive Systems
Kinetix 6000 and Kinetix 6200/6500 (400V-class) Drives/MP-Series Low Inertia Motor Curves
Torque
(N•m)
Torque
(lb•in)
Speed (rpm)
2000 4000 6000 80000
2094-BMP5-S @ 150% or 2094-BMP5-M
and MPL-B1510V
0.800
0.700
0.600
0.500
0.400
0.300
0.200
0.100
0
7.08
6.19
5.31
4.42
3.54
2.65
1.77
0.88
0
Peak curve represents
460V and 400V inputs
Torque
(N•m)
Torque
(lb•in)
Speed (rpm)
2000 4000 6000 80000
2094-BMP5-S @ 250% or 2094-BMP5-M
and MPL-B1520U
1.600
1.400
1.200
1.000
0.800
0.600
0.400
0.200
0
14.1
12.4
10.6
8.85
7.08
5.31
3.54
1.77
0
Peak curve represents
460V and 400V inputs
Torque
(N•m)
Torque
(lb•in)
Speed (rpm)
2000 4000 6000 80000
2094-BMP5-S @ 250% or 2094-BMP5-M
and MPL-B1530U
4.00
3.50
3.00
2.50
2.00
1.50
1.00
0.50
0
35.4
30.9
26.5
22.1
17.7
13.3
8.84
4.42
0
Torque
(N•m)
Torque
(lb•in)
Speed (rpm)
2000 4000 6000 80000
2094-BMP5-S @ 150% or 2094-BMP5-M
and MPL-B210V
1.600
1.400
1.200
1.000
0.800
0.600
0.400
0.200
0
14.1
12.4
10.6
8.85
7.08
5.31
3.54
1.77
0
Peak curve represents
460V and 400V inputs
Torque
(N•m)
Torque
(lb•in)
0
0
1.0
2.0
3.0
5.0
4.0
8.85
17.7
26.5
35.4
44.2
2094-BM01-S @ 150% or 2094-BM01-M
and MPL-B220T
Speed (rpm)
1000
2000 3000 40000 5000
6000
Peak curve represents
460V and 400V inputs
Torque
(N•m)
Torque
(lb•in)
0
0
2.0
4.0
6.0
35.4
53.1
70.8
8.0
88.5
Speed (rpm)
0
3000
5000
4000
1000
2000
10.0
1.77
2094-BM01-S @ 150% or 2094-BM01-M
and MPL-B230P
= Intermittent operating region
= Continuous operating region
= Drive operation with 400V AC rms input voltage
