Rockwell Automation Publication KNX-RM003B-EN-P - March 2019 83
Kinetix 6000 and Kinetix 6200/6500 Drive Systems
Kinetix 6000 and Kinetix 6200/6500 (400V-class) Drives
with MP-Series Linear Stages
This section provides system combination information for the Kinetix 6000 and Kinetix 6200/6500 (400V-class) drives
when matched with MP-Series (400V-class) integrated direct-drive or ballscrew linear stages. Included are power/brake
and feedback cable catalog numbers, system performance specifications, and the optimum force/velocity curves.
Bulletin MPAS Cable Combinations
For cable configuration illustrations and feature descriptions, by catalog number, see 2090-Series Motor/Actuator Cables Overview beginning on page 8.
Motor-end connector kits, and panel-mounted breakout components (drive end), are available for motor power/brake and feedback cables. See Optional Drive Accessories on page 6
.
Cable length xx is in meters. See the Kinetix Motion Accessories Technical Data, publication KNX-TD004
, for standard cable lengths.
Bulletin MPAS Performance Specifications with Kinetix 6200/6500 (400V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with actuator at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, see Motion Analyzer software.
Linear Stage Motor Power/Brake Cable Motor Feedback Cable
(1)
(1) Use low-profile connector kit (catalog number 2090-K6CK-D15M) on the drive end. See Required Drive Accessories on page 4.
MPAS-Bxxxx1-V05SxA
MPAS-Bxxxx2-V20SxA
2090-CPxM7DF-16AAxx (standard, non-flex)
2090-CPxM7DF-16AFxx (continuous-flex)
2090-CFBM7DF-CEAAxx or
2090-CFBM7DD-CEAAxx (standard, non-flex)
2090-CFBM7DF-CEAFxx or
2090-CFBM7DD-CEAFxx (continuous-flex)
Absolute High-resolution Feedback
MPAS-B8xxxx-ALMx2C
MPAS-B9xxxx-ALMx2C
2090-XXNFMF-Sxx (standard, non-flex)
2090-CFBM7DF-CDAFxx (continuous-flex)
Incremental Feedback
Linear Stage
Cat. No.
Speed, max
mm/s (in/s)
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Linear Stage
Rated Output
kW
Kinetix 6200/
Kinetix 6500
400V-class Drives
MPAS-Bxxxx1-V05SxA 200 (7.9)
(1)
(1) For 900 mm stroke length, maximum speed is 176 mm/s (6.9 in/s). For 1020 mm stroke length, maximum speed is 143 mm/s (5.6 in/s).
1.75 521 (117) 3.50 1212 (272) 0.138 2094-BMP5-M
MPAS-Bxxxx2-V20SxA 1124 (44.3)
(2)
(2) For 780 mm stroke length, maximum speed is 889 mm/s (35.0 in/s). For 900 mm stroke length, maximum speed is 715 mm/s (28.2 in/s). For 1020 mm stroke length,
maximum speed is 582 mm/s (22.9 in/s).
3.30 462 (104) 6.60 968 (218) 0.52 2094-BMP5-M
MPAS-B8xxxF-ALMO2C 5000 (200) 3.50 189 (42.5) 9.30 456 (103) 0.527 2094-BMP5-M
MPAS-B8xxxF-ALMS2C 5000 (200) 3.15 159 (35.7) 8.37 399 (89.7) 0.475 2094-BMP5-M
MPAS-B9xxxL-ALMO2C 5000 (200) 3.40 285 (64.1) 9.10 680 (153) 0.768 2094-BMP5-M
MPAS-B9xxxL-ALMS2C 5000 (200) 3.03 245 (55.1) 8.19 601 (135) 0.69 2094-BMP5-M
