88 Rockwell Automation Publication KNX-RM003B-EN-P - March 2019
Kinetix 6000 and Kinetix 6200/6500 Drive Systems
Performance Specifications with Kinetix 6000 (200V-class) Drives
Performance Specifications with Kinetix 6000 (400V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with actuator at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, see Motion Analyzer software.
Electric Cylinder
Cat. No.
Speed, max
mm/s (in/s)
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak Stall
Current
Amps 0-pk
System Peak Stall
Force
N (lb)
Motor Rated
Output
kW
Kinetix 6000
200V-class Drives
MPAR-A1xxxB 150 1.15 240 (53.9) 1.35 300 (67.4) 0.036 2094-AMP5-S
MPAR-A1xxxE 500 2.16 280 (62.9) 2.48 350 (78.7) 0.140 2094-AMP5-S
MPAR-A2xxxC 250 2.42 420 (94.4) 2.72 525 (118) 0.105 2094-AMP5-S
MPAR-A2xxxF 640 4.54 640 (144) 5.41 800 (180) 0.410 2094-AM01-S
MPAR-A3xxxE 500 10.33 2000 (450) 12.34 2500 (562) 1.00 2094-AM02-S
MPAR-A3xxxH 1000 12.20 1300 (292) 16.40 1625 (365) 1.30 2094-AM02-S
Electric Cylinder
Cat. No.
Speed, max
mm/s (in/s)
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Motor Rated
Output
kW
Kinetix 6000
400V-class Drives
MPAR-B1xxxB 150 1.15 240 (53.9) 1.35 300 (67.4) 0.036 2094-BMP5-S @ 150%
MPAR-B1xxxE 500 1.49 280 (62.9) 1.71 350 (78.7) 0.140 2094-BMP5-S @ 150%
MPAR-B2xxxC 250 1.67 420 (94.4) 1.90 525 (118) 0.105 2094-BMP5-S @ 150%
MPAR-B2xxxF 640 3.29 640 (144) 3.93 800 (180) 0.410 2094-BMP5-S @ 150%
MPAR-B3xxxE 500 5.16 2000 (450) 6.17 2500 (562) 1.00 2094-BM01-S @ 150%
MPAR-B3xxxH 1000 6.13 1300 (292) 6.79 1625 (365) 1.30 2094-BM01-S @ 150%
