Publication 1747-RM001G-EN-P - November 2008
SLC Communication Channels 13-7
Configuring a Channel for DH-485
To configure an SLC processor channel for DH-485, do the following using
your programming software:
To bring up the Channel Configuration
interface, double-click on the Channel
Configuration icon.
For an SLC 500 Fixed, SLC 5/01 and
SLC 5/02 processor, enter in the Baud
Rate and Node Address parameters.
For SLC 5/03, SLC 5/04 and SLC 5/05
processors, define the location of the
diagnostic file used for Channel Status
here. See Table 13.2 for diagnostic file
details.
