Allen-Bradley SLC 500 Series - Page 553

Publication 1747-RM001G-EN-P - November 2008
SLC Status File B-33
S:6
continued
xx5A Hardware interrupt problem.
(xx = slot number)
X••••
xx5B G file configuration error - user
program G file size exceeds
capacity of the module.
(xx = slot number)
X••••
xx5C M0-M1 file configuration error -
user program M0-M1 file size
exceeds capacity of the module.
(xx = slot number)
X••••
xx5D Interrupt service requested is
not supported by the processor.
(xx = slot number)
X••••
xx5E Processor I/O driver (software)
error.
(xx = slot number)
X••••
005F Invalid rack ID (handshake error) X•••
xx60
to
xx6F
Identifies an I/O module specific
recoverable major error. Refer to
the user manual supplied with
the specialty module.
(xx = slot number)
X••••
xx70
to
xx7F
Identifies an I/O module specific
non-recoverable major error.
Refer to the user manual
supplied with the specialty
module.
(xx = slot number)
X••••
Table B.3 S:6 Error Codes (Continued)
Address Error
Code
(Hex)
User Program Instruction
Errors
Fault Classification Processor
Non-
User
User Fixed
5/01
5/02 5/03 5/04 5/05
Non-
Recov
Recov
