Publication 1747-RM001G-EN-P - November 2008
B-34 SLC Status File
S:6
continued
xx80
to
xx8F
Identifies a specialty I/O module
specific major error. Refer to the
user manual supplied with the
specialty module.
(xx = slot number)
X•••
xx90 Interrupt problem on disabled
slot.
X••••
xx91 A disabled slot has faulted. X••••
xx92 An invalid or non-existent
module interrupt subroutine
(ISR) file.
X••••
xx93 Unsupported I/O module specific
major error.
X••••
xx94 In the REM Run or REM Test
mode, a module has been
detected as being inserted under
power. This can also mean that
an I/O module has reset itself.
(xx = slot number)
X••••
0x00A0
0x00A1
0x00A2
Indicates a communications
channel hardware fault has
occurred. With the SLC 5/05,
only the Ethernet channel
(channel 1) may generate this
fault. With the SLC 5/04 only the
DH+ channel (channel 1) may
generate this fault. Ethernet,
DH+ and RS-232
communications will be disabled
until a power cycle is performed.
For the SLC 5/05, system status
file word 15 (S:15) provides a
specific fault code for the
Ethernet Daughterboard.
X••
Table B.3 S:6 Error Codes (Continued)
Address Error
Code
(Hex)
User Program Instruction
Errors
Fault Classification Processor
Non-
User
User Fixed
5/01
5/02 5/03 5/04 5/05
Non-
Recov
Recov
