Data File Organization and Addressing E-7
The table on the following page explains the addressing format for outputs
and inputs. Note that the format specifies e as the slot number and s as the
word number. When you are dealing with file instructions, refer to the element
as e.s (slot and word), taken together.
Slot Inputs Outputs
0
1
2
24
6
None
16
6
8
Table E.2 Data File 0 - Output Image
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Slot 0 Outputs (0 to
15)
xO:0
Slot 1 Outputs (0 to
5)
INVALID O:1
Slot 2 Outputs (0 to
7)
xO:2
Table E.3 Data File 1 - Input Image
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Slot 0 Inputs (0 to
15)
x x I:0
Slot 0 Inputs (16 to
23)
INVALID x I:0.1
Slot 1 Inputs (0 to 5) INVALID x I:1
