Example Scanner and Decoder Configuration
Table G.4 Scanner and Decoder Configuration
Scanner Configuration Parameters 2755-DS/DD Series B Enhanced Bar
Code Decoder Configuration
Parameters
Scanner Control Page Host Configurations Page
Discrete I/O: Read Package 25 ms
No-Read Package 25
ms
Baud Rate: 19200
Laser Light: Triggered Bits/Char: 8 Data 1 Stop
Decode Mode: Host Parity: Even
No-Read Time: 2000 ms Host Protocol: DH-485 PCCC-1
Inter Scan Time: none Device
Address:
2
Capture Count: 2 ACK Char: none
Symbols/Scan: 1 NAK Char: none
Symbols/Package
:
1 Large Buffer: No
Match Complete: 1 Send Host
Message:
Package
Immediately after Valid
Transmission
Check:
none
