Monitor the Switch Chapter 8
Table 95 - Stratix 5700 and ArmorStratix 5700 System Status Indicators
Indicator Status Description
Setup The Setup status indicator shows the status of the initial setup of the switch.
The behavior of the Setup status indicator varies depending on whether you run single-mode or multi-mode Express Setup. In multi-mode Express Setup, the
behavior varies based on whether you run Short Press, Medium Press, or Long Press mode. For details about the Setup status indicator behavior during Express
Setup, refer to Chapter 2, Get Started.
EIP Net The EIP Net status indicator shows the network status of the switch.
Off Power to the switch is off or is not properly connected.
Solid green The switch has an established CIP connection to one or more attached devices.
Flashing green The switch has an IP address but the switch does not have an established connection to one or more attached devices.
Flashing red One or more connections to attached devices have timed out.
Solid Red The switch has detected that its IP address is already in use by another device in the network.
Flashing green and red The switch is running its power-on self-test (POST).
EIP Mod The EIP Mod status indicator shows the status of the switch.
Off Power to the switch is off or is not properly connected.
Solid green The switch is operating properly.
Flashing green The switch is not configured. For example, the switch does not have an IP address configured.
Flashing red The switch has detected a recoverable system fault.
Solid red The switch has detected a nonrecoverable system fault.
Flashing green and red The switch is running its power-on self-test (POST).
DC_A/PWR A
DC_B/PWR B
The power status indicators show the status of power to the switch.
Off Power to the switch is off or is not properly connected.
Solid green Power is present on the associated circuit.
Solid red Power is not present on the associated circuit, and the switch is configured for dual-input power.
Alarm IN1
Alarm IN2
The alarm input status indicators show the status of the alarm inputs.
Off Alarm input is not configured.
Solid green Alarm input is configured; no alarm detected.
Flashing red Major alarm detected.
Solid red Minor alarm detected.
Alarm Out The alarm out status indicators show the status of the alarm output.
Off Alarm Out is not configured, or the switch is off.
Solid green Alarm Out is configured; no alarm is detected.
Flashing red The switch has detected a major alarm.
Table 96 - Stratix 5700 and ArmorStratix 5700 Port Status Indicators
Mode Status Description
Status In Status mode, the port status indicators show the connection and activity status of the port. Status mode is the default mode.
