Allen-Bradley Stratix 8000 User Manual

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 447
Data Types Appendix A
AllPortsUtilization SINT Decimal
PortGi1_1Utilization SINT Decimal
PortGi1_2Utilization SINT Decimal
PortGi1_3Utilization SINT Decimal
PortGi1_4Utilization SINT Decimal
PortGi1_5Utilization SINT Decimal
PortGi1_6Utilization SINT Decimal
PortGi1_7Utilization SINT Decimal
PortGi1_8Utilization SINT Decimal
PortGi1_9Utilization SINT Decimal
PortGi1_10Utilization SINT Decimal
PortGi1_11Utilization SINT Decimal
PortGi1_12Utilization SINT Decimal
PortGi1_13Utilization SINT Decimal
PortGi1_14Utilization SINT Decimal
PortGi1_15Utilization SINT Decimal
PortGi1_16Utilization SINT Decimal
PortGi1_17Utilization SINT Decimal
PortGi1_18Utilization SINT Decimal
PortGi1_19Utilization SINT Decimal
PortGi1_20Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MinorAlarmRelay BOOL Decimal AlarmRelay:1
MulticastGroupActive DINT Binary
Table 134 - Output Data Type (20-Gb port switches)
AB:STRATIX_5400_20PORT_GB_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
AllPortsDisabled BOOL Decimal DisablePort:0
PortGi1_1Disable BOOL Decimal DisablePort:1
PortGi1_2Disable BOOL Decimal DisablePort:2
PortGi1_3Disable BOOL Decimal DisablePort:3
PortGi1_4Disable BOOL Decimal DisablePort:4
PortGi1_5Disable BOOL Decimal DisablePort:5
PortGi1_6Disable BOOL Decimal DisablePort:6
PortGi1_7Disable BOOL Decimal DisablePort:7
PortGi1_8Disable BOOL Decimal DisablePort:8
Table 133 - Input Data Type (20-port Gb switches) (continued)
AB:STRATIX_5400_20PORT_GB_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
