448 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017

Appendix A Data Types

PortGi1_9Disable BOOL Decimal DisablePort:9

PortGi1_10Disable BOOL Decimal DisablePort:10

PortGi1_11Disable BOOL Decimal DisablePort:11

PortGi1_12Disable BOOL Decimal DisablePort:12

PortGi1_13Disable BOOL Decimal DisablePort:13

PortGi1_14Disable BOOL Decimal DisablePort:14

PortGi1_15Disable BOOL Decimal DisablePort:15

PortGi1_16Disable BOOL Decimal DisablePort:16

PortGi1_17Disable BOOL Decimal DisablePort:17

PortGi1_18Disable BOOL Decimal DisablePort:18

PortGi1_19Disable BOOL Decimal DisablePort:19

PortGi1_20Disable BOOL Decimal DisablePort:20

Table 134 - Output Data Type (20-Gb port switches) (continued)

AB:STRATIX_5400_20PORT_GB_MANAGED:O:0

Member Name Type Default Display

Style

Valid Values

Default Chapter2
