x530L Series Installation Guide for Virtual Chassis Stacking
189
2 Enter the ENABLE command to move from the User Exec mode to the Privileged
Exec mode.
awplus> enable
Steps 3 and 4 set the switch’s priority value to be the same as its ID number.
3 Move to the Global Configuration mode with the CONFIGURE TERMINAL command.
awplus# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
4 Assign a priority value to the switch equal to its ID number, with the STACK
PRIORITY. This example assigns priority 2 to a member switch with the ID 2:
awplus(config)# stack 2 priority 2
Steps 5 and 6 remove the stacking function from the default stacking ports 9 and 10 on the
member switch.
5
Enter the port Interface modes of the default stacking ports 9 and 10 on the member
switch. The example here assumes the member switch has the ID 2:
awplus(config)# interface port2.0.9-2.0.10
% port1.0.9 is currently configured as a stack-port. Use caution when
altering its config.
% port1.0.10 is currently configured as a stack-port. Use caution
when altering its config.
6
Remove the stacking function from the ports to convert them into regular Ethernet
ports, with the NO STACKPORT command:
awplus(config-if)# no stackport
% Save the config and restart the system for this change to take
effect.
Steps 7 and 8 add the stacking function to the optional stacking ports on the member switch.
7 Enter the Interface modes of the optional stack ports on the member switch. If you
filled out the worksheet in Table 18 on page 85, refer there for the ports. The example
command here assumes the switch has the ID 2 and will be using ports 7 and 8 for the
stack trunk. Be sure to modify the command with the ports you selected for the stack
trunk.
awplus(config-if)# interface port2.0.7-2.0.8
Table 29. Configuring the x530L-10GHXm Member Switches - Part II (Continued)
Step Description and Command
To Next Page
