Chapter 1: Overview
20
The back panels on the x530L Series switches are shown in Figure 7
through Figure 10 on page 20.
Figure 7. x530L-10GHXm Back Panel
Figure 8. x530L-18GHXm Back Panel
Figure 9. x530L-52GPX and x530L-28GPX Back Panel
Figure 10. x530L-52GTX and x530L-28GTX Back Panel
AC Power
Supply
Connector
AC Power
Supply
Connector
100-240 VAC~ 100-240 VAC~
PSU 2 PSU 1
4586
AC Power
Supply
Connector
AC Power
Supply
Connector
100-240VAC~
4587
100-240VAC~
PSU 2 PSU 1
AC Power
Supply
Connector
AC Power
Supply
Connector
