Chapter 8: Building the Stack Trunk with 5Gbps Multi-Speed Ports
170
Configuring the
Master x530L-
10GHXm Switch
– Part II
In Part II, you add the member switches as provisioned units to the master
switch and designate their 5Gbps trunk ports. Adding member switches as
provisioned devices ensures that the master switch is aware of them
during the first stack power-on. The procedure assumes you are
continuing directly from the previous procedure.
The remaining steps save your changes.
13
Return to the Global Configuration mode with the EXIT command:
awplus(config-if)# exit
14
Return to the Privileged Exec mode.
awplus(config)# exit
15
Enter the WRITE command to save your change. If this is the first management session,
the switch adds the configuration file DEFAULT.CFG to flash memory, for storing your
configuration changes. If you do not save your changes, they will be discarded and you
will have to re-enter them when you reboot the switch later in these procedures.
awplus# write
Building configuration ...
[OK]
16
Go to “Configuring the Master x530L-10GHXm Switch – Part II,” next.
Table 22. Configuring the Master x530L-10GHXm Switch for 5Gbps Stacking Ports – Part I
Step Description and Command
Table 23. Configuring the Master x530L-10GHXm Switch for 5Gbps Stacking Ports – Part II
Step Description and Command
Steps 1 to 2 add the member switches as provisioned switches on the master switch. This is so the
master switch is aware of the switches when the stack is powered on for the first time.
1
Move to the Global Configuration mode with the CONFIGURE TERMINAL command.
awplus# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
2
Add the member switches to the master switch as provisioned switches with the SWITCH
PROVISION command. Assign a unique ID number, in the range of 2 to 8, to each unit.
The following examples add three provisioned member switches to the master switch,
with the IDs 2 to 4:
awplus(config)# switch 2 provision x530L-10
awplus(config)# switch 3 provision x530L-10
awplus(config)# switch 4 provision x530L-10
